STANDARD UNIT ACCESSORIES
LINE SETS	• Prefabricated with quick connects for easy installation • Lines are pre-flared with connection nuts on each end • Sized and paired for appropriate system • Lines are insulated to prevent sweating • Available in 15’ and 30’ lengths
LINE-HIDE, LINESET COVER SYSTEM	• Easy to install, modular system • Protects line sets, drain lines and wiring • Snap on covers and full selection of couplings, elbows, T- joints, caps and more for any application (complex or simple) • High quality PVC with UV inhibitors for outdoor service in all weather conditions • Can be painted with most house paints to match exterior decors • Not just for HVAC use. Can be used to hide any exterior cabling, piping or wiring
CONDENSATE PUMPS	•Can be installed inside the evaporator, remotely above ceiling or inside line set cover • Quiet – only 33 dB(A) • Self priming pump - suction lift to 4ft • Cleanable stainless steel filter • Automatically operates on water rise and handles up to 0.8 g/h @ 26ft Head • Push-in electrical terminals for quick connection of power and alarm wires • Volt free N/O & N/C contacts switch off unit and activate optional alarm • Kit includes all components required
MOUNTING BRACKETS	• For wall or roof mounting the condensing unit • Adjustable to fit any size/manufacturers condensing unit • Cadmium plated hardware for weather resistance • Rubber mounts for vibration isolation
